Cams &
Camshafts

Custom cams and camshafts engineered from various materials, from drawings or samples

We are a leading custom camshaft manufacturer based in the UK, renowned for producing high-quality cams and camshafts. At Polgain, we design, manufacture, regrind and reverse engineer cams and camshafts for a wide range of industries. Whether you’re seeking bespoke solutions for tailored performance enhancements or require large-scale production runs, we specialise in custom industrial cams and specialised one-off projects.

Using advanced CNC machining and precision measurement equipment, we ensure every component meets exact specifications and performs reliably in demanding environments.

Send us your drawing
Casting
Forging
Material Selection
Heat Treatment

Custom Cams

Polgain manufactures and regrinds a wide variety of cam types, including:

  • Plate cams
  • Barrel cams
  • Swing arm cams
  • Globoidal cams
  • Winding cams
  • Conjugate cams

Each cam is produced with the required accuracy, profile, and surface finish to meet operational needs. We work from drawings, CAD data, or supplied samples, and where required, can reverse engineer worn components to create accurate replacements.

Cam Grinding

Our CNC machining centres, combined with Adcole Cam Contour Measuring Machines, allow us to maintain extremely tight tolerances. Profile accuracy is verified through deviation graphs and phasing angle reports, ensuring consistency from prototype through to full production.

Our advanced capabilities allow us to grind plate cam profiles up to 1300mm in diameter and barrel cams up to 900mm in diameter, ensuring unmatched accuracy and performance.

Cam manufacturers

Cams are manufactured from a range of materials, chosen to suit the specific application and heat treatment process. Hardened and ground cam tracks are often recommended, as they improve wear resistance and extend service life in high-load applications.

Applications for our cams include:

  • Power generation equipment
  • Glass industry machines
  • Automotive development and motorsport
  • Classic and prestige engineering projects
  • Heavy-duty diesel and marine engines
Three different cams
Camshafts on wooden beams

Camshaft Design and Manufacturing

Polgain has extensive capability in the manufacture and refurbishment of camshafts, from small motorcycle components through to large marine diesel camshafts.

Using our CNC Landis camshaft grinding machines, we can produce camshafts up to 1,800mm in length with a minimum inverse radius of 70mm. Additional features such as polygons, flats, and eccentrics can also be generated where required.

All camshafts are inspected using our Adcole contour measuring machines to verify profile geometry, alignment, and tolerances. This data can be provided to customers as part of a detailed inspection report.

Send us your drawing

Manufacturing Process

  • Material selection – chosen to match strength, durability, and heat treatment requirements.
  • CNC machining – precision turning and milling using Haas CNC equipment.
  • Heat treatment – to achieve hardness and wear resistance.
  • Grinding and finishing – using CNC Landis grinders and Schiess Kopp CNC profile grinding machines.
  • Inspection – full CMM and Adcole profile measurement with digital reporting available.



A sample of the business sectors supported is:

  • Motorsport and automotive development
  • Power generation
  • Classic and prestige vehicle restoration
  • Marine and heavy diesel engines
  • Special-purpose machinery

Supporting Your Project with Skilled Engineering Expertise

Our headquarters is home to a skilled and approachable team dedicated to supporting your next project, whether you require component procurement or bespoke engineering services. We proudly serve a broad spectrum of industries, including motorsport, prestige automotive, classic vehicles, power generation, matrix dresser cams, and automotive development, delivering customised solutions for every need.
